TECHNICAL FEATURES

CONVEYING DISTANCE————————————— from 6.3 up to 15.8 M
BELT WIDTH—————————————————- 360 MM
MAX DISCHARGE RATE————————————— 70M3 / H
ROTATION——————————————————- 310°
MAX DISCHARGE HEIGHT———————————– 7M
WEIGHT——————————————————— 3170 KG
STEEL STRUCTURE
PROPORTIONAL HYDRAULICS
STABILIZERS

Service and profitability at every step !

The best versatility :
360° non-stop rotating chute
3D extension ideal for shuttered walls
Reduce penibility on site, avoid the several in/out of the cabin

The best investment :
Several options in standard (3D extension, double rubber hopper, chute extension, hard covering chain system…)
Payload of 6m3 concrete*
*depends on truck and mixer configuration

High quality delivery :
Sliding system preventing concrete segregation
Can deliver every kind of concrete plasticity and gravels
Hood with quick opening for cleaning

Optional equipements :
High pressure washer
High voltage power line detector (HTA et HTB)
Remote support in the cabin with connector
Mixer chute UP/Down from the conveyor remote
